N7 Mobile Terminal

Product specifications
  • Dimension
    200×70×24mm
  • Weight
    360g
  • Sealing
    IP65
  • Network Connection
    WLAN, WWAN, WPAN
  • Operating System
    Android
  • Screen Size
    4.0"
Features
  • 1D Barcode
    1D Barcode
  • 2D Barcode
    2D Barcode
  • IP65
    IP65
  • Android
    Android
  • GPS
    GPS
  • 4G
    4G
  • WiFi
    WiFi
Vertical
  • Warehouse
    Warehouse
  • Transportation & Logistic
    Transportation & Logistic
  • Features
  • Specifications
  • Downloads
  • Accessories
Features
  • Excellent grip, rugged and durable

  • Specially designed for logistics, warehouse and other industry fields, custom 29 buttons layout. Combined with ergonomic pistol grip designing. IP65 protection grade, withstand 1.8m free drop to concrete (2 times at each surface) and work normally in pouring water situation with gloved fingers.

  • High accuracy medium range identification

  • Using international top class 1D laser scan engine and 2D CMOS scan engine; Support medium far distance scanning; Using 25°perfect scanning angel, make scanning more accurate; 8 megapixel camera, high dynamic LED light, easy to capture clear photos at any time and any place.

  • Qualcomm platform Android 10.0

  • Using Qualcomm platform, Octa-core, 1.8GHzd main frequency, running Android 10.0 operating system, providing quicker data process and smoother operation.

  • Type-C port WIFI ac band

  • Using the mainstream Type-C fast charging port, the charging power is up to 18W, can fully charge the 5100mAh battery within 2 hours. Support 802.11ac band and WIFI 5G band, faster transmission rate and better support for WIFI roaming.



Specifications
Performance
Processor Qualcomm 1.8GHz, octa cores 64-bit processor
Operating System Android 10.0
Memory 3GB RAM, 32GB ROM/4GB RAM, 64GB ROM
Interface QC3.0, Type-C port, 9V/2A
Physical
Dimensions 200×70 (pistol grip 58) ×24 (battery29) mm
Weight 360g (including battery)
Display 4.0" WVGA IPS screen with Gorilla Glass, resolution 480×800, support with gloves or water touch
Keypad 29 physical buttons, with back light function, able to extend to 38 or 47 buttons
Virtual Button Support three virtual buttons
Notification Vibration, speaker and multi-color LEDs
Battery 5100mAh, support spare battery
Camera 13MP, PDAF, with LED flashlight
GPS GPS (A-GPS)/GLONASS or GPS (A-GPS)/Galileo
Expansion Micro SD/TF card (max. 128GB)
Sensor Gravity sensor, hall switch
AC Adapter QC3.0, Output: Type-C 5V/2A,9V/2A,15V/1.2A, Input: AC 100~240V,50~60Hz
Environmental
Operating Temperature -20℃ to 50℃ (-4°F to 122°F)
Storage Temperature -40℃ to 70℃ (-40°F to 158°F)
Humidity 5% to 95% (non-condensing)
Static Discharge ±15 kV (Air discharge), ±8 kV (Direct discharge)
Drop 1.8m drops to concrete (for six sides, two drops per side)
Sealing IP65
Barcode Scanning
2D Barcode CMOS (≥ 5 mil) Aztec, Composite, CS Code, Maxicode, Micro PDF, Micro QR, PDF 417, QR Code, Data Matrix, DotCode.
1D Barcode CMOS (≥ 5 mil) Code128, Code 49, Code 16K, (GS1128) UCC/EAN-128, AIM-128, EAN-8, EAN-13, UPC-E, UPC-A, ITF, ITF 6, ITF 14, Matrix 2 of 5, Industrial 25, Standard 2 of 5, Code39, ISSN, ISBN, Codabar, Code93, Code 11, Plessey, MSI Plessey, RSS.
Depth of Field
Depends on Barcode Type and Environment Code39 (5mil) 80mm-350mm; Code39 (10mil) 50mm-575mm
Code128 (3mil) 100mm-180mm; Code128 (10mil) 60mm-480mm
EAN-13 (13mil) 40mm-480mm; DM (15mil) 55mm-355mm
PDF417 (10mil) 60mm-320mm; QR (15mil) 50mm-400mm
MR
Code39(5mil) 200mm-575mm; Code39(10mil) 150mm-575mm
Code128(10mil) 180mm-680mm
EAN-13(13mil) 130mm-705mm; DM(15mil) 185mm-520mm
PDF417(10mil) 175mm-550mm; QR(15mil) 195mm-550mm
NFC
13.56MHz RFID 13.56MHz ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693
Wireless
WLAN RADIO Bands built-in 802.11 a/b/g/n/ac, compatible with 11 d/h/i/k/r/v/w, support 2.4G and 5G dual frequency
Roaming Support Fast Roaming
Bluetooth Dual mode, BT4.2+LE (Backward-compatible)
Card Slots
IF Card TF
Accessory
Accessory AC adapter, cable, charging cradle, hand strap, 4-slot charger
Certificates&Protect
Certificates CE-RED, FCC, BIS, RoHS2.0, REACH, AER, SOTI, UN38.3, IEC62471
Laser Safety IEC60825
