MT90

MT90 RFID

Mobile Terminal
MT90

MT90 RFID

Mobile Terminal
Mobile Terminal
Mobile Terminal

MT90 RFID Mobile Terminal

Product specifications
  • Dimension
    155×78×20mm
  • Weight
    265g
  • Sealing
    IP67, IP65
  • Network Connection
    WLAN, WWAN, WPAN
  • Operating System
    Android
  • Screen Size
    5”
Features
  • 2D Barcode
    2D Barcode
  • 1D Barcode
    1D Barcode
  • Android
    Android
  • 1.5m
    1.5m
  • GPS
    GPS
  • IP65
    IP65
  • 4G
    4G
  • WiFi
    WiFi
Vertical
  • Retail
    Retail
  • Warehouse
    Warehouse
  • Transportation & Logistic
    Transportation & Logistic
  • Features
  • Specifications
  • Downloads
  • Accessories
Features

5” Multi-color Capacitive Touch Screen

The NLS-MT90 Mobile Terminal with tempered glass and IPS display boasts a good viewing angle and is quite legible for indoor and outdoor use.

Diverse Functionalities

Beyond the flexibility of its dual SIM card system, the NLS-MT90 offers Bluetooth/1D/2D/BT/Wi-Fi/4G/3G/GPS/Camera/NFC functionalities to meet various application needs.

Industrial-grade Durability

The NLS-MT90’s rugged housing is sealed to IP65 standards for protection against dust and water and withstands 1.5m drops to concrete.

Superior Barcode Reading Performance

Armed with Newland’s sixth-generation of technology and its state-of-the-art 2D mega-pixel engine, the new NLS-MT90 can decode even poorer quality barcodes, such as soiled or wrinkled labels, with ease.








Specifications
Performance
Processor 2.0GHz, octa-core 64-bit processor
Operating System Android 11
Memory RAM: 4GB ROM: 64GB
Interface Micro USB 2.0 OTG at the bottom, 8 Pin extended contact on the back
Physical
Dimensions Maximum Size: 155 × 78 × 20mm;
Handheld Size: 155 × 76 × 18mm
Weight 270g (including battery)
Display 5” (1280×720) capacitive touch screen
Keypad 10 keys (side keys included)
Notification Vibration, speaker and multi-color LEDs
Battery 3.8V, 4500mAh
Camera Front camera (optional): 2 megapixels
Rear camera: 8 megapixels, auto focus, with LED flashlight
GPS GPS(AGPS), GLONASS, Beidou
Expansion Micro SD card (max. 128GB) slot
AC Adapter Output: DC5V, 2.0A Input: AC100~240V, 50~60Hz
Environmental
Operating Temperature -20℃ to 55℃ (-4°F to 131°F)
Storage Temperature -40℃ to 70℃ (-40°F to 158°F)
Humidity 5% to 95% (non-condensing)
Static Discharge ±15 kV (Air discharge), ±8 kV (Direct discharge)
Drop 1.5m drops to concrete (for six sides, one drop per side)
Sealing IP65 or IP67 (optional)
Tumble Spec. 0.5m, 10 times/min, 500 times(250 tumbles)
Barcode Scanning
1D Barcode CMOS (≥ 5 mil) 1D: Code128, UCC/EAN-128, AIM-128, EAN-8, JAN-8, EAN-3, ISBN/ISSN, UPC-E, UPC-A, Interleave2/5, ITF-6, ITF-14, Deutsche14, Deutsche12, COOP25, Matrix2/5, Industrial2/5, Standard25, Code39, Codabar/NW7, Code93, Code 11, Plessey, MSI/Plessey, GS1 Databar, etc.
2D Barcode CMOS (≥ 5 mil) 2D: PDF-417, QR Code, Data Matrix, Chinese Sensible Code, Aztec, Maxicode, etc.
Depth of Field
Depends on Barcode Type and Environment Code39(20mil) 90mm-600mm; EAN13(13mil) 60mm-420mm
Code39(5mil) 102mm-205mm; DM(10mil) 110mm-275mm
PDF417(6.7mil) 90mm-173mm; QR(15mil) 40mm-230mm
NFC
13.56MHz RFID ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693
Wireless
WLAN RADIO IEEE 802.11 a/b/g/n/ac, 2.4GHz and 5GHz
WWAN RADIO 2G: GSM:850/900/1800/1900MHz
3G: WCDMA: B1/B2/B4/B5/B8; CDMA 1x/EVDO: BC0/BC1
4G: FDD-LTE: B1/B2/B3/B4/B7/B12/B13/B17; TDD-LTE: B41
WPAN RADIO Bluetooth 5.0 (backward-compatible)
Optional
Optional AC adapter, cable, battery, charging cradle, wrist lanyard, trigger handle, RFID handheld reader, long-range barcode reader, protective sleeve, etc.
