NQuire1000

Interactive Kiosk

NQuire1000

Interactive Kiosk

NQuire1000

Interactive Kiosk

NQuire1000

Interactive Kiosk

NQuire1000

Name: Interactive KioskNQuire1000
Brand: Interactive KioskNQuire1000
Availability: InStock

Interactive Kiosk

문의하기

제품 사양

운영 시스템
Android 13
스크린 사이즈
10.1”
인터페이스
USB, Ethernet, Expansion
네트워크 연결
WLAN, WPAN , Ethernet
다이멘션
140 × 139.5 x 61 mm
디코드 지원
2D Barcode, 1D Barcode

특징

2D 바코드
1D 바코드
안드로이드(Android)
USB
이더넷
와이파이(WiFi)
10.1''

적용분야

리테일
웨어하우스
헬스케어
공공 부문

특징
사양
다운로드
악세서리

특징

Easily Build Applications

The NQuire is built on Android 13, allowing for easy development of custom applications.

Easy to Install and Use Anywhere

Ideally suited for shelf mounting or on-counter usage in department stores, supermarkets, small grocery stores, drugs-cosmetic stores, tobacco kiosks, and more.

Highly Customizable with a Broad Range of Features

External SCR, Thermal Printer, Wi-Fi, Bluetooth embedded, Coms included POE.

Snappy Reading Performance

Armed with Newland’s omnidirectional megapixel EM2037 engine (Resolution: 1280*800).

사양

Performance	Processor	2.0GHz, octa-core 64-bit processor
	Operating System	Android 13（can be upgrade to higher version）
	Memory	4GB RAM/64GB ROM
	Symbologies	2D:Aztec, Composite, CS Code, Maxicode, Micro PDF, Micro QR, PDF 417, QR Code, Data Matrix, DotCode. 1D: Code128, Code 49, Code 16K, (GS1128) UCC/EAN-128, AIM-128, EAN-8, EAN-13, UPC-E, UPC-A, ITF, ITF 6, ITF 14, Matrix 2 of 5, Industrial 25, Standard 2 of 5, Code39, ISSN, ISBN, CodaBar, Code93, Code 11, Plessey, MSI Plessey, RSS.
	Depth of Field (Depend on Barcode and Environment)	EAN-13 : 70mm-610mm(13mil) Code39 : 110mm-290mm(5mil) PDF417 : 110mm-230mm(6.7mil) Data Matrix : 110mm-260mm(10mil) QR Code : 55mm-410mm(15mil)

Physical/Electrical	Dimensions	251.7(L) × 173.5(W) × 32(H) mm
	Display	10.1” (1280×800), capacitive touch screen
	Keypad	Up/down keys, Vol+/Vol-keys, Menu key
	Notification	speaker and multi-color LEDs
	Sensor	Gravity Sensor, infrared sensor
	GPS	GPS (AGPS), GLONASS, Beidou, Galileo
	Camera	Front camera: 8 megapixels,
	Audio	1x Microphone, 2x Speakers 8Ω/1.5W
	Card	Nano+Nano/Nano+TF
	Interface	USB : 1x USB Type-C, 1x USB Type-A Ethernet : RJ45, support Power-over-Ethernet Expansion : 2x GPIO/1x expansion USB/2x series port
	AC Adapter	AC Adapter : 12V@3A POE : IEEE 802.3 af/at

Environmental	Operating Temperature	-10℃ to 50℃ (14°F to 122°F)
	Storage Temperature	-20℃ to 60℃ (-4°F to 140°F)
	Humidity	5% to 90% (non-condensing)
	Sealing	IP54

NFC

13.56MHz RFID(Optional)

ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693
Support ID Card reading, support reader/writer mode

Wireless	WLAN	Built-in 802.11 a/b/g/n/ac, support 2.4G and 5G dual frequency
	WWAN RADIO (4G version only)	2G : 850/900/1800/1900MHz 3G : WCDMA (B1, B2, B5, B8); CDMA: 1X EVDO (BC0); TD-SCDMA: B34/39 4G : TDD-LTE (B34, B38, B39, B40, B41), FDD-LTE (B1, B2, B3, B5, B7, B8, B20, B28 a&b)
	WPAN RADIO	Bluetooth 5.2

Accessory (Optional)

NFC antenna, MSR card reader

Performance

Processor
2.0GHz, octa-core 64-bit processor

Operating System
Android 13（can be upgrade to higher version）

Memory
4GB RAM/64GB ROM

Symbologies
2D:Aztec, Composite, CS Code, Maxicode, Micro PDF, Micro QR, PDF 417, QR Code, Data Matrix, DotCode. 1D: Code128, Code 49, Code 16K, (GS1128) UCC/EAN-128, AIM-128, EAN-8, EAN-13, UPC-E, UPC-A, ITF, ITF 6, ITF 14, Matrix 2 of 5, Industrial 25, Standard 2 of 5, Code39, ISSN, ISBN, CodaBar, Code93, Code 11, Plessey, MSI Plessey, RSS.

Depth of Field (Depend on Barcode and Environment)
EAN-13 : 70mm-610mm(13mil) Code39 : 110mm-290mm(5mil) PDF417 : 110mm-230mm(6.7mil) Data Matrix : 110mm-260mm(10mil) QR Code : 55mm-410mm(15mil)

Physical/Electrical

Dimensions
251.7(L) × 173.5(W) × 32(H) mm

Display
10.1” (1280×800), capacitive touch screen

Keypad
Up/down keys, Vol+/Vol-keys, Menu key

Notification
speaker and multi-color LEDs

Sensor
Gravity Sensor, infrared sensor

GPS
GPS (AGPS), GLONASS, Beidou, Galileo

Camera
Front camera: 8 megapixels,

Audio
1x Microphone, 2x Speakers 8Ω/1.5W

Card
Nano+Nano/Nano+TF

Interface
USB : 1x USB Type-C, 1x USB Type-A Ethernet : RJ45, support Power-over-Ethernet Expansion : 2x GPIO/1x expansion USB/2x series port

AC Adapter
AC Adapter : 12V@3A POE : IEEE 802.3 af/at

Environmental

Operating Temperature
-10℃ to 50℃ (14°F to 122°F)

Storage Temperature
-20℃ to 60℃ (-4°F to 140°F)

Humidity
5% to 90% (non-condensing)

Sealing
IP54

NFC

13.56MHz RFID(Optional)
ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693 Support ID Card reading, support reader/writer mode

Wireless

WLAN
Built-in 802.11 a/b/g/n/ac, support 2.4G and 5G dual frequency

WWAN RADIO (4G version only)
2G : 850/900/1800/1900MHz 3G : WCDMA (B1, B2, B5, B8); CDMA: 1X EVDO (BC0); TD-SCDMA: B34/39 4G : TDD-LTE (B34, B38, B39, B40, B41), FDD-LTE (B1, B2, B3, B5, B7, B8, B20, B28 a&b)

WPAN RADIO
Bluetooth 5.2

Accessory (Optional)

NFC antenna, MSR card reader

다운로드

제품 브로셔

NLS-NQuire1000_Datasheet_en_global

NLS-NQuire1000_Datasheet_en_global

언어: English

다운로드

사용자 메뉴얼

Newland_Android_NQuire_API_Handbook

Newland_Android_NQuire_API_Handbook

언어: English

다운로드
NQuire_Application_Programming_Manual

NQuire_Application_Programming_Manual

언어: English

다운로드
NLS-NQuire1000_User_Guide

NLS-NQuire1000_User_Guide

언어: English

다운로드
