デコード能力
1D, 2D -
接続性
Corded -
寸法
-
重量
-
シーリング
IP54 -
インターフェース
USB, RS-232,
-
特徴
-
仕様
-
付属品
Equipped with Auto Train Function
Equipped with Auto Train Function
Excellent DPM Decoding Capability
High Protection Industrial Structure Design
High-Resolution Image Sensor
NVF230 can support Auto-Train function. By Learning, NVF230 automatically selects the best settings for the given reading situation, based on parameters of illumination, camera and decoder properties. This feature to create an optimum setting to read your codes.
Provide white and red direct illumination, blue diffuse ring lights, rich lighting system can meet different materials (such as reflection), shape (curved surface), background and bar code color of all kinds of complex scanning code needs.
With the new generation of industrial decoding algorithm, it has strong decoding ability for DPM barcodes such as radium carving and dotting barcodes.
The NLS-NVF230, built into an IP54-sealed and can prevent the critical components from splashing water and dust. That ensures the scanner has a long-term reliable scanning performance.
Using 1280×800 megapixels image sensor, the scanner can decode 3mil barcodes.
Performance | Image Sensor | 1280 × 800 CMOS |
Illumination | Red LED(AP) White LED(SR/HD/HHD) |
|
Symbologies | 2D:QR Code, PDF417, Micro QR, Data Matrix. 1D:EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Code 128, Code 39, Codabar, UCC/EAN 128, AIM128, Interleaved 2 of 5, ITF-14, ITF-6, Standard 2 of 5, Matrix 2 of 5, COOP 25, Industrial 2 of 5, Plessey, MSI Plessey, Code 11, Code 93, ISBT128, Deutsche14, Deutsche12. |
|
Resolution | ≥3mil | |
Typical Depth of Field | NVF230-SR: EAN-13(13mil):50-340mm Code 39(5mil):75-175mm Data Matrix(10mil):50-200mm QR Code(15mil):50-290mm NVF230-HD/AP EAN-13(13mil):70-165mm Code 39(5mil):60-120mm Data Matrix(10mil):50-115mm QR Code(15mil):30-145mm NVF230-HHD: QR Code(5.6mil):30-40mm QR Code(6.7mil):28-53mm |
|
Scan Angle | Roll: 360°, Pitch: ±50°, Skew: ±50° | |
Min. Symbol Contrast | 25% | |
Field of View | Horizontal 48.5°, Vertical 30.7° |
Physical | Dimensions (L×W×H) | 45(W)×51(D)×25(H) |
Weight | 176g | |
Notification | Beep, LED indicator | |
Current | operating: White LED: 387mA (typical), 571mA (max). RED LED: 387mA (typical), 477mA (max). standby:58mA |
|
Interfaces | USB, RS232, Ethernet. | |
Operating Voltage | 5VDC±5% | |
Input | Maximum 15mA (input power: 5V ~ 30V); 1 channel | |
Outputs | Maximum 60mA (input power≤30V); 2 channels | |
Rated Power Consumption | White LED: 1859mW (typical) RED LED: 1859 mW (typical) |
Environmental | Operating Temperature | -20°C to 60°C(-4°F to 140°F) |
Storage Temperature | -40°C to 70°C(-40°F to 158°F) | |
Humidity | 5% to 95% (non-condensing) | |
ESD | ±16 KV (air discharge); ±8 KV (direct discharge) | |
Drop | 1.5m | |
Sealing | IP54 |
Certifications | Certifications | FCC, CE, ROHS, IEC62471, BIS. |
Image Sensor | |
---|---|
1280 × 800 CMOS |
Illumination | |
---|---|
Red LED(AP) White LED(SR/HD/HHD) |
Symbologies | |
---|---|
2D:QR Code, PDF417, Micro QR, Data Matrix. 1D:EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Code 128, Code 39, Codabar, UCC/EAN 128, AIM128, Interleaved 2 of 5, ITF-14, ITF-6, Standard 2 of 5, Matrix 2 of 5, COOP 25, Industrial 2 of 5, Plessey, MSI Plessey, Code 11, Code 93, ISBT128, Deutsche14, Deutsche12. |
Resolution | |
---|---|
≥3mil |
Typical Depth of Field | |
---|---|
NVF230-SR: EAN-13(13mil):50-340mm Code 39(5mil):75-175mm Data Matrix(10mil):50-200mm QR Code(15mil):50-290mm NVF230-HD/AP EAN-13(13mil):70-165mm Code 39(5mil):60-120mm Data Matrix(10mil):50-115mm QR Code(15mil):30-145mm NVF230-HHD: QR Code(5.6mil):30-40mm QR Code(6.7mil):28-53mm |
Scan Angle | |
---|---|
Roll: 360°, Pitch: ±50°, Skew: ±50° |
Min. Symbol Contrast | |
---|---|
25% |
Field of View | |
---|---|
Horizontal 48.5°, Vertical 30.7° |
Dimensions (L×W×H) | |
---|---|
45(W)×51(D)×25(H) |
Weight | |
---|---|
176g |
Notification | |
---|---|
Beep, LED indicator |
Current | |
---|---|
operating: White LED: 387mA (typical), 571mA (max). RED LED: 387mA (typical), 477mA (max). standby:58mA |
Interfaces | |
---|---|
USB, RS232, Ethernet. |
Operating Voltage | |
---|---|
5VDC±5% |
Input | |
---|---|
Maximum 15mA (input power: 5V ~ 30V); 1 channel |
Outputs | |
---|---|
Maximum 60mA (input power≤30V); 2 channels |
Rated Power Consumption | |
---|---|
White LED: 1859mW (typical) RED LED: 1859 mW (typical) |
Operating Temperature | |
---|---|
-20°C to 60°C(-4°F to 140°F) |
Storage Temperature | |
---|---|
-40°C to 70°C(-40°F to 158°F) |
Humidity | |
---|---|
5% to 95% (non-condensing) |
ESD | |
---|---|
±16 KV (air discharge); ±8 KV (direct discharge) |
Drop | |
---|---|
1.5m |
Sealing | |
---|---|
IP54 |
Certifications | |
---|---|
FCC, CE, ROHS, IEC62471, BIS. |
