雙雷射瞄準可在安裝時輕鬆定位設備位置，簡單方便。
支援透過USB介面快速向主機傳輸數據。
金屬外殼達到IP65防護等級，堅固可靠。
可將特定區域的影像以多種格式傳輸。
針對醫療行業優化的解碼演算法。高解碼精度，將讀取錯誤降至最低。
這款迷你條碼掃描器可輕鬆整合到IVD設備中。
近距離讀取具廣的掃描範圍。
Performance | Image Sensor | 800*1280 CMOS |
| Illumination | 3000K white LED | |
| Aimer | 650nm red laser aiming LEDs*2 | |
| Field of View | Horizontal 52°, Vertical 76.5° | |
| Beam Exit | Scan window with lateral beam exit | |
| Depth of Field | Code 39 (6.67mil): 45-85mm Code 128 (5mil): 30-80mm Code 128 (10mil): 35-130mm QR (15mil): 15-165mm Data Matrix (10mil): 20-120 |
|
| Resolution | ≥5mil | |
| Symbologies | 1D: Code 128, EAN-8, EAN-13, UPC-E, UPC-A, Interleaved 2/5, Code 39, Codabar, Code 93, UCC/EAN-128 2D: PDF417, QR Code, Aztec, Data Matrix. |
|
| Min. Symbol Contrast | 50% |
Physical | Operating Voltage | 5VDC±5% |
| Current | Operating: 141.35mA RMS (typical), 397.54mA (max.) | |
| Housing | Aluminium | |
| Dimensions | 54(W)×27.5(D)×25.5(H)mm (max.) (without cable) | |
| Weight | 107g | |
| Cable | USB-A: 1.5m 9-pin connection cable: 2m |
Environmental | Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) | |
| Humidity | 5% to 95% (non-condensing) | |
| Sealing | IP65 | |
| Ambient Light | ≤5000lux |
Certification | CE/FCC IEC62471: 2006 for LED safety 60825-1:2014 for laser safety RoHS 2.0 |
| Image Sensor | |
|---|---|
| 800*1280 CMOS | |
| Illumination | |
|---|---|
| 3000K white LED | |
| Aimer | |
|---|---|
| 650nm red laser aiming LEDs*2 | |
| Field of View | |
|---|---|
| Horizontal 52°, Vertical 76.5° | |
| Beam Exit | |
|---|---|
| Scan window with lateral beam exit | |
| Depth of Field | |
|---|---|
| Code 39 (6.67mil): 45-85mm Code 128 (5mil): 30-80mm Code 128 (10mil): 35-130mm QR (15mil): 15-165mm Data Matrix (10mil): 20-120 |
|
| Resolution | |
|---|---|
| ≥5mil | |
| Symbologies | |
|---|---|
| 1D: Code 128, EAN-8, EAN-13, UPC-E, UPC-A, Interleaved 2/5, Code 39, Codabar, Code 93, UCC/EAN-128 2D: PDF417, QR Code, Aztec, Data Matrix. |
|
| Min. Symbol Contrast | |
|---|---|
| 50% | |
| Operating Voltage | |
|---|---|
| 5VDC±5% | |
| Current | |
|---|---|
| Operating: 141.35mA RMS (typical), 397.54mA (max.) | |
| Housing | |
|---|---|
| Aluminium | |
| Dimensions | |
|---|---|
| 54(W)×27.5(D)×25.5(H)mm (max.) (without cable) | |
| Weight | |
|---|---|
| 107g | |
| Cable | |
|---|---|
| USB-A: 1.5m 9-pin connection cable: 2m |
|
| Operating Temperature | |
|---|---|
| 0°C to 50°C (32°F to 122°F) | |
| Storage Temperature | |
|---|---|
| -20°C to 70°C (-4°F to 158°F) | |
| Humidity | |
|---|---|
| 5% to 95% (non-condensing) | |
| Sealing | |
|---|---|
| IP65 | |
| Ambient Light | |
|---|---|
| ≤5000lux | |
| CE/FCC IEC62471: 2006 for LED safety 60825-1:2014 for laser safety RoHS 2.0 |
|
