NVF260 Healthcare Scanner,Healthcare Barcode Scanners manufacturer
Healthcare Scanner supplier

NVF260

Healthcare Scanner
Healthcare Scanner

NVF260 Healthcare Scanner

Product specifications
  • Decode Capability
    1D, 2D
  • Connectivity
    Corded
  • Dimension
    Height: 100mm Diameter: 65mm
  • Weight
    332g
  • Sealing
    IP64
  • Interface
    USB
Features
  • CMOS
    CMOS
  • 1D Barcode
    1D Barcode
  • 2D Barcode
    2D Barcode
  • USB
    USB
  • RS232
    RS232
  • 1.2 drop
    1.2 drop
  • IP64
    IP64
Vertical
  • Healthcare
    Healthcare
  • Manufacturing
    Manufacturing
  • Features
  • Specifications
  • Downloads
Features
  • Advanced Illumination System

  • Blue diffuse ring lights can avoid reflection of metal materials. It is efficient to scan barcodes on anodised aluminum, shiny chrome objects.

  • Easy to Sanitize and Clean

  • Medical grade sterilized appearance prevents alcohol damage. It can be easily santized and cleaned for daily use in the hospitals.

  • Excellent DPM Decoding Capability

  • With the new generation of industrial decoding algorithm, it has strong decoding ability for DPM barcodes such as dot-peen barcodes.

  • High-Resolution Image Sensor

  • Using 1280×800 megapixels image sensor, the scanner can decode 3mil barcodes. NVF260 has unparalled performance on reading tiny and curved barcodes on medicine bottles, IV bags, syringes. Barcodes can be printed, laser cut, engraved or etched in different materials, shapes, bakground and colors.

  • Humanized Illumination Designation

  • The HR3280-BT can be set white and red led according to different workplaces. Not only relieving the visual fatigue but also improving working efficiency.

  • User-friendly Connectivty

  • The NLS-NVF260 can be powered and connected to a computer via USB port. The users can set the NLS-NVF260 without additional cables.

Specifications
Performance
Image Sensor 1280×800 (megapixel) CMOS
Illumination Diffuse: Ring of blue LED
Symbologies 2D
1D
QR Code, Data Matrix, PDF 417
EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Code 128, Code 39, Codabar, UCC/EAN 128, AIM128, Interleaved 2 of 5, ITF-14, ITF-6, Standard 2 of 5, Matrix 2 of 5, COOP 25, Industrial 2 of 5, Plessey, MSI Plessey, Code 11, Code 93, ISBT128, Deutsche14, Deutsche12.
Resolution ≥3mil
Typical Depth of Field Data Matrix
Data Matrix
QR Code
0-20mm (6.7mil)
0-25mm (10mil)
0-30mm (10mil)
Scan Angle Pitch: ±45°, Roll: 360°, Skew: ±45°
Min. Symbol Contrast 25%
Field of View Horizontal 32.7°, Vertical 20.7°
Physical
Dimensions (L×W×H) Height: 100mm, Diameter: 65mm
Weight 332g
Notification Beep, LED
Rated Power Consumption 1275mW (typical)
Current@5VDC Operating 230mA (typical), 255mA (max)
Interfaces USB
Operating Voltage 5VDC±5%
Environmental
Operating Temperature -20°C to 60°C (-4°F to 140°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity 5%~95% (non-condensing)
ESD ±8 KV (direct discharge); ±15 KV (air discharge)
Drop 1.2m/3.94ft.
Sealing IP64
Certifications
Certificates & Protection FCC Part15 Class B, CE EMC Class B. RoHS
Performance
Image Sensor
1280×800 (megapixel) CMOS
Illumination
Diffuse: Ring of blue LED
Symbologies
2D
1D
QR Code, Data Matrix, PDF 417
EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Code 128, Code 39, Codabar, UCC/EAN 128, AIM128, Interleaved 2 of 5, ITF-14, ITF-6, Standard 2 of 5, Matrix 2 of 5, COOP 25, Industrial 2 of 5, Plessey, MSI Plessey, Code 11, Code 93, ISBT128, Deutsche14, Deutsche12.
Resolution
≥3mil
Typical Depth of Field
Data Matrix
Data Matrix
QR Code
0-20mm (6.7mil)
0-25mm (10mil)
0-30mm (10mil)
Scan Angle
Pitch: ±45°, Roll: 360°, Skew: ±45°
Min. Symbol Contrast
25%
Field of View
Horizontal 32.7°, Vertical 20.7°
Physical
Dimensions (L×W×H)
Height: 100mm, Diameter: 65mm
Weight
332g
Notification
Beep, LED
Rated Power Consumption
1275mW (typical)
Current@5VDC
Operating 230mA (typical), 255mA (max)
Interfaces
USB
Operating Voltage
5VDC±5%
Environmental
Operating Temperature
-20°C to 60°C (-4°F to 140°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Humidity
5%~95% (non-condensing)
ESD
±8 KV (direct discharge); ±15 KV (air discharge)
Drop
1.2m/3.94ft.
Sealing
IP64
Certifications
Certificates & Protection
FCC Part15 Class B, CE EMC Class B. RoHS
Downloads
Specification Sheets
  • NLS-NVF260_Datasheet_en_global
    NLS-NVF260_Datasheet_en_global

    Language: English

Manual & Technical Literature
  • NLS-NVF260_User_Guide
    NLS-NVF260_User_Guide

    Language: English

Software
  • NSet
    NSet

    Language: English

  • USB-COM_Driver
    USB-COM_Driver

    Language: English
