MT93 Full-touch

Product specifications

Dimension
159×74×15.9mm
Weight
277g
Sealing
IP67
Network Connection
WLAN, WWAN, WPAN
Operating System
Android
Screen Size
5.5"

Features

2D Barcode
1D Barcode
Android
GPS
WiFi
WiFi Dual Band

Vertical

Retail
Warehouse
Transportation & Logistic

Features
Specifications
Downloads
Accessories

Features

Diverse Functionalities

The NLS-MT93 offers 1D/2D/BT/Wi-Fi 6/4G /GPS/Camera/NFC functionalities to meet different application needs. Equipped with Newland’s self-developed high performance barcode reading engine, the NLS-MT93 can decode various barcodes and support OCR character recognition.

Heavily Customized Android

The value-added features of the NLS-MT93 including application protection and admin tool, seek to shore up Android’s data security.

Long Expected Battery Life

The NLS-MT93 is equipped with a 5000mAh battery that provides a full-shift battery life of up to 12 hours from a single charge. What’s more, the battery is changeable which guarantees the all-day continue use of device.

Rugged Durability

The NLS-MT93’s rugged housing is sealed to IP67 standards for protection against dust and water and withstands 1.5m drops to concrete.

Specifications

Performance	Processor	2.2GHz, octa-core 64-bit processor
	Operating Interface System	Android 13
	Memory	4GB RAM, 64GB ROM
	Symbologies	2D: Aztec, Composite, CS Code, Maxicode, Micro PDF, Micro QR, PDF 417, QR Code, Data Matrix, DotCode. 1D: Code128, Code 49, Code 16K, (GS1128) UCC/EAN-128, AIM-128, EAN-8, EAN-13, UPC-E, UPC-A, ITF, ITF 6, ITF 14, Matrix 2 of 5, Industrial 25, Standard 2 of 5, Code39, ISSN, ISBN, CodaBar, Code93, Code 11, Plessey, MSI Plessey, RSS.
	Depth of Field (Depend on Barcode and Environment)	EAN-13: 70mm-610mm(13mil) Code39: 120mm-290mm(5mil) PDF417: 110mm-230mm(6.7mil) Data Matrix: 110mm-260mm(10mil) QR Code: 55mm-410mm(15mil)

Physical	Dimensions	159(L) × 74(W) × 15.9(H) mm
	Weight	277g (including battery)
	Display	5.5” (720×1440), multi-point capacitive touch screen with Gorilla Glass，Brightness(max.400 Nits)
	Keypad	Virtual on-screen buttons: Menu, Home, Back Physical buttons: Left and right Scan keys, Volume +/-, Power
	Notification	Vibrator, speaker(8R,1W 10cm,103dB) and multi-color LEDs
	Battery	3.85V, 5000mAh
	GPS	GPS (AGPS), GLONASS, Beidou, Galileo
	Camera	Front camera: 5 megapixels, Rear camera: 13 megapixels, auto focus, with LED flashlight
	Interface	Type-C 2.0 OTG，Type-C earphone
	AC Adapter	18W Fast Charging Supported
	Card Slots	Nano+Nano
	Sensors	Light & Proximity sensor, accelerometer sensor, magnetic sensor, gyroscope sensor
	NFC	13.56MHz RFID: ISO14443A/B, ISO15693, ISO18000-3, MIFARE, FeliCa RF, Kovio, NFC Forum Type 1-4 Tags
	Expansion	Micro SD Card ( Maximum 256GB) ,2 PIN contacts support Pistol grip
	Interface	USB Type-C , charging contacts on the bottom, supports headphones
	SIM Slots	Nano+Nano or Nano+TF
	AC Adapter	Output: DC5V/7V/9V, 2A Input: AC100~240V, 50~60Hz, 18W Fast charge

Environmental	Operating Temperature	-20℃ to 55℃ (-4°F to 131°F)
	Storage Temperature	-40℃ to 70℃ (-40°F to 158°F)
	Humidity	5% to 95% (non-condensing)
	Static Discharge	±15 kV (Air discharge), ±8 kV (Direct discharge)
	Drop	1.5m drops to concrete (for six sides, one drop per side)
	Sealing	IP67

Wireless	WLAN RADIO	Built-in 802.11 a/b/g/n/ac, support 2.4G and 5G dual frequency
	WWAN RADIO	2G: 850/900/1800/1900MHz 3G: WCDMA (B1, B2, B5, B8); CDMA: 1X EVDO (BC0); TD-SCDMA: B34/B39 4G: TDD-LTE (B34, B38, B39, B40, B41); FDD-LTE (B1, B2, B3, B5, B7, B8, B20, B28 a&b)
	WPAN RADIO	Bluetooth 5.2 BLE backward compatibility

Accessory	In device package	Battery, AC adapter, USB cable, hand strap, Rubber boot, protective film,
	Optional	Pistol grip, charging cradle, 4-slot battery charging cradle, high-Volte adaptor

Performance

Processor
2.2GHz, octa-core 64-bit processor

Operating Interface System
Android 13

Memory
4GB RAM, 64GB ROM

Symbologies
2D: Aztec, Composite, CS Code, Maxicode, Micro PDF, Micro QR, PDF 417, QR Code, Data Matrix, DotCode. 1D: Code128, Code 49, Code 16K, (GS1128) UCC/EAN-128, AIM-128, EAN-8, EAN-13, UPC-E, UPC-A, ITF, ITF 6, ITF 14, Matrix 2 of 5, Industrial 25, Standard 2 of 5, Code39, ISSN, ISBN, CodaBar, Code93, Code 11, Plessey, MSI Plessey, RSS.

Depth of Field (Depend on Barcode and Environment)
EAN-13: 70mm-610mm(13mil) Code39: 120mm-290mm(5mil) PDF417: 110mm-230mm(6.7mil) Data Matrix: 110mm-260mm(10mil) QR Code: 55mm-410mm(15mil)

Physical

Dimensions
159(L) × 74(W) × 15.9(H) mm

Weight
277g (including battery)

Display
5.5” (720×1440), multi-point capacitive touch screen with Gorilla Glass，Brightness(max.400 Nits)

Keypad
Virtual on-screen buttons: Menu, Home, Back Physical buttons: Left and right Scan keys, Volume +/-, Power

Notification
Vibrator, speaker(8R,1W 10cm,103dB) and multi-color LEDs

Battery
3.85V, 5000mAh

GPS
GPS (AGPS), GLONASS, Beidou, Galileo

Camera
Front camera: 5 megapixels, Rear camera: 13 megapixels, auto focus, with LED flashlight

Interface
Type-C 2.0 OTG，Type-C earphone

AC Adapter
18W Fast Charging Supported

Card Slots
Nano+Nano

Sensors
Light & Proximity sensor, accelerometer sensor, magnetic sensor, gyroscope sensor

NFC
13.56MHz RFID: ISO14443A/B, ISO15693, ISO18000-3, MIFARE, FeliCa RF, Kovio, NFC Forum Type 1-4 Tags

Expansion
Micro SD Card ( Maximum 256GB) ,2 PIN contacts support Pistol grip

Interface
USB Type-C , charging contacts on the bottom, supports headphones

SIM Slots
Nano+Nano or Nano+TF

AC Adapter
Output: DC5V/7V/9V, 2A Input: AC100~240V, 50~60Hz, 18W Fast charge

Environmental

Operating Temperature
-20℃ to 55℃ (-4°F to 131°F)

Storage Temperature
-40℃ to 70℃ (-40°F to 158°F)

Humidity
5% to 95% (non-condensing)

Static Discharge
±15 kV (Air discharge), ±8 kV (Direct discharge)

Drop
1.5m drops to concrete (for six sides, one drop per side)

Sealing
IP67

Wireless

WLAN RADIO
Built-in 802.11 a/b/g/n/ac, support 2.4G and 5G dual frequency

WWAN RADIO
2G: 850/900/1800/1900MHz 3G: WCDMA (B1, B2, B5, B8); CDMA: 1X EVDO (BC0); TD-SCDMA: B34/B39 4G: TDD-LTE (B34, B38, B39, B40, B41); FDD-LTE (B1, B2, B3, B5, B7, B8, B20, B28 a&b)

WPAN RADIO
Bluetooth 5.2 BLE backward compatibility

Accessory

In device package
Battery, AC adapter, USB cable, hand strap, Rubber boot, protective film,

Optional
Pistol grip, charging cradle, 4-slot battery charging cradle, high-Volte adaptor

Downloads

Specification Sheets

NLS-MT93_4G_A13_Datasheet_APAC_EN.pdf

NLS-MT93_4G_A13_Datasheet_APAC_EN.pdf

Language: English

Download

Manual & Technical Literature

MT93singlepage_online.pdf

MT93singlepage_online.pdf

Language: English

Download
NLS-MT93_A13_User Guide_EN.pdf

NLS-MT93_A13_User Guide_EN.pdf

Language: English

Download
