Equipped with the latest AI-powered barcode positioning technology, the NLS-NVH220 improves decoding performance for low-contrast barcodes. Additionally, intelligent learning enables automatic parameter adjustments based on different scenarios.
Provides red and blue direct illumination and white diffuse lights. The versatile lighting system accommodates various materials (such as reflective surfaces), shapes (such as curved surfaces), backgrounds, and barcode colors, meeting diverse and complex scanning requirements.
Featuring the latest UlMG ® decoding system, it enhances decoding success rates for complex barcodes, optimizing workflows and improving overall decoding efficiency. It also delivers exceptional decoding performance for DPM barcodes, including laser-etched and dot-peened markings.
The NLS-NVH220-HD, built into an IP64-sealed and can withstand repeated falls from 1.8 meters to the ground, with excellent reliability and stability.
The NLS-NVH220 features an upgraded dual-core processing platform that enhances computing capability and efficiency, enabling faster, more stable decoding with lower power consumption.
Performance | Image Sensor | 1280 × 800 CMOS | |
| Illumination | Direct: red & blue LEDs; Diffuse: white LED; |
||
| Aiming | 650nm, crosshair laser | ||
| Symbologies | 2D: QR Code, PDF417, Micro QR, Data Matrix, AZTEC. 1D: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, Code 39, AIM 128, GS1 Composite, GS1-128(UCC/EAN), ISBT 128 Code 11, MSI-Plessey, Plessey, etc. |
||
| Resolution | ≥3mil | ||
| Typical Depth of Field | EAN-13(13mil) : 10mm-280mm Code 39(5mil) : 30mm-180mm Code 39(20mil) : 50mm-440mm Data Matrix(10mil) : 15mm-140mm QR Code(20mil) : 10mm-250mm |
||
| Scan Angle | Roll: 360°, Pitch: ±50°, Skew: ±50° | ||
| Min. Symbol Contrast | 20% | ||
| Motion Tolerance | 2m/s | ||
| Field of View | Horizontal 42°，Vertical 28° | ||
Physical | Dimensions (L×W×H) | 68 (W) × 86 (D) × 180(H) mm | |
| Weight | 160g(without cable) | ||
| Notification | Beep, LED indicator, Vibrator | ||
| Current | Operating (typical) 300mA Operating (max.) 450mA |
||
| Interfaces | USB, RS232 | ||
| Operating Voltage | 5VDC±5% | ||
| Rated Power Consumption | 1500mW（typical） | ||
Environmental | Operating Temperature | -20°C to 50°C(-4°F to 122°F) | |
| Storage Temperature | -40°C to 70°C(-40°F to 158°F) | ||
| Humidity | 5% to 95% (non-condensing) | ||
| ESD | ±16 KV (air discharge); ±8 KV (direct discharge) | ||
| Drop | 1.8m | ||
| Sealing | IP64 | ||
| Certifications | FCC,CE,ROHS,IEC62471,BIS,KC | ||
| Accessories | USB(Used to connect the NVH220 to a host device.) RS-232(AC adapter,Input 100-240V,output DC 5V/1.5A) |
||
| Image Sensor | |
|---|---|
| 1280 × 800 CMOS | |
| Illumination | |
|---|---|
| Direct: red & blue LEDs; Diffuse: white LED; |
|
| Aiming | |
|---|---|
| 650nm, crosshair laser | |
| Symbologies | |
|---|---|
| 2D: QR Code, PDF417, Micro QR, Data Matrix, AZTEC. 1D: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, Code 39, AIM 128, GS1 Composite, GS1-128(UCC/EAN), ISBT 128 Code 11, MSI-Plessey, Plessey, etc. |
|
| Resolution | |
|---|---|
| ≥3mil | |
| Typical Depth of Field | |
|---|---|
| EAN-13(13mil) : 10mm-280mm Code 39(5mil) : 30mm-180mm Code 39(20mil) : 50mm-440mm Data Matrix(10mil) : 15mm-140mm QR Code(20mil) : 10mm-250mm |
|
| Scan Angle | |
|---|---|
| Roll: 360°, Pitch: ±50°, Skew: ±50° | |
| Min. Symbol Contrast | |
|---|---|
| 20% | |
| Motion Tolerance | |
|---|---|
| 2m/s | |
| Field of View | |
|---|---|
| Horizontal 42°，Vertical 28° | |
| Dimensions (L×W×H) | |
|---|---|
| 68 (W) × 86 (D) × 180(H) mm | |
| Weight | |
|---|---|
| 160g(without cable) | |
| Notification | |
|---|---|
| Beep, LED indicator, Vibrator | |
| Current | |
|---|---|
| Operating (typical) 300mA Operating (max.) 450mA |
|
| Interfaces | |
|---|---|
| USB, RS232 | |
| Operating Voltage | |
|---|---|
| 5VDC±5% | |
| Rated Power Consumption | |
|---|---|
| 1500mW（typical） | |
| Operating Temperature | |
|---|---|
| -20°C to 50°C(-4°F to 122°F) | |
| Storage Temperature | |
|---|---|
| -40°C to 70°C(-40°F to 158°F) | |
| Humidity | |
|---|---|
| 5% to 95% (non-condensing) | |
| ESD | |
|---|---|
| ±16 KV (air discharge); ±8 KV (direct discharge) | |
| Drop | |
|---|---|
| 1.8m | |
| Sealing | |
|---|---|
| IP64 | |
| Certifications | |
|---|---|
| FCC,CE,ROHS,IEC62471,BIS,KC | |
| Accessories | |
|---|---|
| USB(Used to connect the NVH220 to a host device.) RS-232(AC adapter,Input 100-240V,output DC 5V/1.5A) |
|
