Armed with Newland’s six-generation of UIMG® technology, the scan engine can swiftly and effortlessly decode even poor quality barcodes (e.g., low contrast, laminated, damaged, torn, warped or wrinkled).
Keeping up with emerging technologies, the NLS-CM30 provides IIC and MIPI interfaces to enable easy integration with the latest processors.
Seamless integration of imager sensor and aimer makes the scan engine extremely small and lightweight and easy to fit into miniature equipment.
The advanced technology incorporated in the scan engine helps reduce its power consumption and prolong its service life.
Performance | Image Sensor | 640*480 CMOS | |
| Illumination | White LED | ||
| Aiming | Red LED (625nm) | ||
| Symbologies | 2D PDF417, QR Code, Data Matrix 1D code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar,Interleaved 2 of 5, ITF-6,ITF-14, ISBN, Code 93,UCC/EAN-128, GS1Databar, Matrix 2 of 5,Code 11,Industrial 2 of 5, Standard 2 of 5.Plessey, MSPlessey |
||
| Resolution* | ≥3mil | ||
| Typical Depth of Field* | EAN-13(13mil):60mm-330mmCode 39 (5mil):65mm-150mmPDF417(6.7mil):60mm-120mmData Matrix(10mil):50mm-120mm OR Code(15mil):35mm-180mm |
||
| Min.Symbol Contrast* | 25% | ||
| Scan Angle** | Roll: 360°, Pitch: ±60°, Skew: ±60° | ||
| Field of View | Horizontal42°, Vertical 31.5° | ||
Mechanical/
Electrical | Interface | IIC, MIPI | |
| Operating Voltage | 3.3VDC+5% | ||
| Rated Power Consumptiont | Operating105mA(typical),110mA(max.) Standby 27mA Idle <100uA |
||
| Dimensions | 8.8(D)x21.5(W)x7.0(H)mm(max.) | ||
| Weight | 1.1g | ||
Environmental | Operating Temperature | -20°C to 55°C | |
| Storage Temperature | -40°C to 70°C | ||
| Humidity | 5% to 95% (non-condensing) | ||
| Ambient Light | 0~100,000lux (natural light) | ||
Certifications | Certificates & Protection | FCC Part15 Class B, CE EMC Class B, ROHS, IEC62471 | |
Accessories | Cable | Optional 34-PIN board to board cable used to connect the EVK-CM60 to a host device | |
| Image Sensor | |
|---|---|
| 640*480 CMOS | |
| Illumination | |
|---|---|
| White LED | |
| Aiming | |
|---|---|
| Red LED (625nm) | |
| Symbologies | |
|---|---|
| 2D PDF417, QR Code, Data Matrix 1D code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar,Interleaved 2 of 5, ITF-6,ITF-14, ISBN, Code 93,UCC/EAN-128, GS1Databar, Matrix 2 of 5,Code 11,Industrial 2 of 5, Standard 2 of 5.Plessey, MSPlessey |
|
| Resolution* | |
|---|---|
| ≥3mil | |
| Typical Depth of Field* | |
|---|---|
| EAN-13(13mil):60mm-330mmCode 39 (5mil):65mm-150mmPDF417(6.7mil):60mm-120mmData Matrix(10mil):50mm-120mm OR Code(15mil):35mm-180mm |
|
| Min.Symbol Contrast* | |
|---|---|
| 25% | |
| Scan Angle** | |
|---|---|
| Roll: 360°, Pitch: ±60°, Skew: ±60° | |
| Field of View | |
|---|---|
| Horizontal42°, Vertical 31.5° | |
| Interface | |
|---|---|
| IIC, MIPI | |
| Operating Voltage | |
|---|---|
| 3.3VDC+5% | |
| Rated Power Consumptiont | |
|---|---|
| Operating105mA(typical),110mA(max.) Standby 27mA Idle <100uA |
|
| Dimensions | |
|---|---|
| 8.8(D)x21.5(W)x7.0(H)mm(max.) | |
| Weight | |
|---|---|
| 1.1g | |
| Operating Temperature | |
|---|---|
| -20°C to 55°C | |
| Storage Temperature | |
|---|---|
| -40°C to 70°C | |
| Humidity | |
|---|---|
| 5% to 95% (non-condensing) | |
| Ambient Light | |
|---|---|
| 0~100,000lux (natural light) | |
| Certificates & Protection | |
|---|---|
| FCC Part15 Class B, CE EMC Class B, ROHS, IEC62471 | |
| Cable | |
|---|---|
| Optional 34-PIN board to board cable used to connect the EVK-CM60 to a host device | |
