MT67

Keyboard

MT67

Keyboard

MT67

Keyboard
NLS-MT67+Mobile+Terminal-final.mp4
Keyboard
Keyboard
Keyboard
Keyboard

MT67 Keyboard

Product specifications
  • Dimension
    162 x 68 x 17mm
  • Weight
    250g
  • Sealing
    IP67, IP65
  • Network Connection
    WLAN, WWAN, WPAN
  • Operating System
    Android
  • Screen Size
    4.0"
Features
  • 2D
    2D
  • 1D Barcode
    1D Barcode
  • Android
    Android
  • GPS
    GPS
  • IP65
    IP65
  • 4G
    4G
  • WiFi
    WiFi
Vertical
  • Warehouse
    Warehouse
  • Transportation & Logistic
    Transportation & Logistic
  • Features
  • Specifications
  • Downloads
Features
  • Android 11 platform

  • Using high performance, Octa-core, 2.0GHzd main frequency, running Android 11.0 operating system, providing quicker data process and smoother operation.

  • Excellent grip, rugged and durable

  • Specially designed for logistics, warehouse and other industry fields. Combined with ergonomic pistol grip designing. IP65/IP67(OPT.) protection grade, withstand 1.5m free drop to concrete (1 time at each surface) and work normally in pouring water situation with gloved fingers.

  • Superior Barcode Reading Performance

  • When equipped with Newland’s UIMG fifth-generation technology, the new NLS-MT67 can decode even poorer quality barcodes, such as soiled or wrinkled labels, with ease.

  • Type-C port WIFI ac band

  • Using the mainstream Type-C fast charging port, the charging power is up to 15W, can fully charge the 4800mAh battery within 3 hours. Support 802.11ac band and WIFI 5G band, faster transmission rate and better support for WIFI roaming.

Specifications
Performance
Processor 2.0 GHz, octa cores 64-bit processor
Operating System Android 11
Memory 4GB RAM, 64GB ROM
Interface USB Type -C, battery charging over USB supported, support USB earphone
Physical
Dimensions 162(L) × 68(W) × 17(H) mm
Weight 250g (including battery)
Display 4”WVGA (800×480) capacitive touch screen,corning gorilla glass
Keypad 24 keys (side keys included) with backlight+3 Virtual keys
Notification Vibrator, speaker and multi-color LEDs
Battery 3.8V, 4800mAh
Camera Front camera: 5 megapixels;
Rare camera: 13 megapixels, auto focus, with LED flashlight
GPS GPS (AGPS), GLONASS
Expansion Micro SD/TF card (max. 128GB)
Sensor Light & Proximity sensor, accelerometer sensor
AC Adapter Output: DC5/7/9V, 1.67A ; Input: AC100~240V, 50~60Hz; Support fast charging
Environmental
Operating Temperature
Storage Temperature
Humidity
Static Discharge
Drop
Sealing
Barcode Scanning
2D Barcode CMOS (≥ 5 mil)
Depth of Field
Depends on Barcode Type and Environment
NFC
13.56MHz
Wireless
WLAN
Performance
Processor
2.0 GHz, octa cores 64-bit processor
Operating System
Android 11
Memory
4GB RAM, 64GB ROM
Interface
USB Type -C, battery charging over USB supported, support USB earphone
Physical
Dimensions
162(L) × 68(W) × 17(H) mm
Weight
250g (including battery)
Display
4”WVGA (800×480) capacitive touch screen,corning gorilla glass
Keypad
24 keys (side keys included) with backlight+3 Virtual keys
Notification
Vibrator, speaker and multi-color LEDs
Battery
3.8V, 4800mAh
Camera
Front camera: 5 megapixels;
Rare camera: 13 megapixels, auto focus, with LED flashlight
GPS
GPS (AGPS), GLONASS
Expansion
Micro SD/TF card (max. 128GB)
Sensor
Light & Proximity sensor, accelerometer sensor
AC Adapter
Output: DC5/7/9V, 1.67A ; Input: AC100~240V, 50~60Hz; Support fast charging
Environmental
Operating Temperature
Storage Temperature
Humidity
Static Discharge
Drop
Sealing
Barcode Scanning
2D Barcode CMOS (≥ 5 mil)
Depth of Field
Depends on Barcode Type and Environment
NFC
13.56MHz
Wireless
WLAN
Downloads
Specification Sheets
  • NLS-MT67_android11_EU_Datasheet_en_global.pdf
    NLS-MT67_android11_EU_Datasheet_en_global.pdf

    Language: English

Manual & Technical Literature
  • NLS-MT67_11_UserGuide_en.pdf
    NLS-MT67_11_UserGuide_en.pdf

    Language: English
