Integrated with advanced AI algorithms and ISP functionality, the NLS-Soldier180 delivers exceptional barcode reading performance in challenging industrial environments, including low-contrast, multi-code, and cluttered backgrounds, significantly enhancing decoding accuracy and stability.
With advanced liquid lens autofocus technology, the NLS-Soldier180 enables fast and precise focus control, offering high flexibility in reading.
NLS-Soldier180 integrates RS-232 and Ethernet interfaces (supporting Profinet, Ethernet/IP, and ModbusTCP), and includes two I/O ports for input and output.
Through the NSet software, the scanner can be configured with a variety of functions, including device grouping, multi-barcode output, script editing, and more. Equipped with powerful self-learning capabilities, the device enables one-click image and scanning setup, greatly simplifying scanner configuration.
Featuring an IP65-rated protection and a compact design, it is suitable for complex and space-constrained industrial environments.
The Soldier 180N-P and Soldier 180S-P offer different angle options, both equipped with direct and polarized lighting for versatile illumination. Compatible with accessories such as magnifier, diffuser, and reflector, they are designed to meet a wide range of application needs.
Performance | Model Type | Soldier180W: mega-pixel Sub model type: Soldier180W-SP: long-distance type Soldier180W-NP: standard type Soldier180E: 2 mega-pixel Sub model type: Soldier180E-SP: long-distance type Soldier180E-NP: standard type |
|
| Sensor | CMOS image sensor | ||
| Number of Pixels | Soldier180W: 1280 × 960 pixels Soldier180E: 1600 × 1200 pixels |
||
| Focus | Liquid lens | ||
| Illumination | Soldier180W/Soldier180E: 4 High-intensity red LEDs(Standard) Soldier180W: WhiteLED/blue LED/ultraviolet LED/infraredLED (Optional) |
||
| Polarized Filter | Half polarized(standard) | ||
| Effective Focal Length | 13.7mm(Soldier180W-SP/Soldier180E-SP) 6.8mm(Soldier180W-NP/Soldier180E-NP) |
||
| Field of View | Horizontal 15.2°(Soldier180W-SP/Soldier180E-SP) Vertical 11.3°(Soldier180W-NP/Soldier180E-NP) |
||
| Supported symbol | 1D: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN,Codabar, Code128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, Code 39,Code 11,MSI-Plessey, Plessey, Deutsche14, Deutsche12 2D: QR Code, Data Matrix, PDF417, Aztec Code, Micro QR |
||
| Minimum Resolution | Soldier180W: 1D: 0.8mil(Soldier180W-SP), 1mil(Soldier180W-NP) 2D: 2mil(Soldier180W-SP), 2mil(Soldier180W-NP) Soldier180E: 1D: 0.613mil(Soldier180E-SP), 0.68mil(Soldier180E-NP) 2D: 0.8mil(Soldier180E-SP), 1.3mil(Soldier180E-NP) |
||
| Reading Distance | Soldier180W: 40 to 1500mm(Soldier180W-SP), 40 to 1000mm(Soldier180W-NP) Soldier180E: 40 to 2000mm(Soldier180E-SP), 40 to 1000mm(Soldier180E-NP) |
||
| Motion Tolerance | 2m/s | ||
| Min. Symbol Contrast | ≥25% | ||
Physical | Dimensions | 45(W) × 59.2(D) × 25(H) mm | |
| Weight | 185g | ||
| Prompt | Buzzer,LED | ||
| Current @24V DC | Operating: 200mA (max) Standy: 70mA |
||
| Input | Minimum ON voltage：±5V；Maximum rated voltage：±30V；2 inputs | ||
| Output | Maximum rated current：50mA per channel；Maximum voltage（OFF state）：±30V；2 outputs | ||
| Communication Interface | RS-232,TCP/IP, UDP, FTP, Modbus TCP,Ethernet/IP,Profinet,MELSEC/SLMP | ||
Environmental | Operating Temperature | -20°C to 50°C(-4°F to 122°F) | |
| Storage Temperature | -40°C to 70°C(-40°F to 158°F) | ||
| Humidity | 5% to 95% (non-condensing) | ||
| ESD | ±16 KV (air discharge); ±8 KV (direct discharge) | ||
| Sealing | IP65 | ||
Accessories | Cable | Ethernet cable, RS232+I/O cable Reflector(optional), Magnifier(optional) |
|
| Adapter | Input 100-240V, output DC 24V/1.5A | ||
| Other | Fixed bracket, Diffuser(optional), Reflector(optional), Magnifier(optional) | ||
| Model Type | |
|---|---|
| Soldier180W: mega-pixel Sub model type: Soldier180W-SP: long-distance type Soldier180W-NP: standard type Soldier180E: 2 mega-pixel Sub model type: Soldier180E-SP: long-distance type Soldier180E-NP: standard type |
|
| Sensor | |
|---|---|
| CMOS image sensor | |
| Number of Pixels | |
|---|---|
| Soldier180W: 1280 × 960 pixels Soldier180E: 1600 × 1200 pixels |
|
| Focus | |
|---|---|
| Liquid lens | |
| Illumination | |
|---|---|
| Soldier180W/Soldier180E: 4 High-intensity red LEDs(Standard) Soldier180W: WhiteLED/blue LED/ultraviolet LED/infraredLED (Optional) |
|
| Polarized Filter | |
|---|---|
| Half polarized(standard) | |
| Effective Focal Length | |
|---|---|
| 13.7mm(Soldier180W-SP/Soldier180E-SP) 6.8mm(Soldier180W-NP/Soldier180E-NP) |
|
| Field of View | |
|---|---|
| Horizontal 15.2°(Soldier180W-SP/Soldier180E-SP) Vertical 11.3°(Soldier180W-NP/Soldier180E-NP) |
|
| Supported symbol | |
|---|---|
| 1D: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN,Codabar, Code128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, Code 39,Code 11,MSI-Plessey, Plessey, Deutsche14, Deutsche12 2D: QR Code, Data Matrix, PDF417, Aztec Code, Micro QR |
|
| Minimum Resolution | |
|---|---|
| Soldier180W: 1D: 0.8mil(Soldier180W-SP), 1mil(Soldier180W-NP) 2D: 2mil(Soldier180W-SP), 2mil(Soldier180W-NP) Soldier180E: 1D: 0.613mil(Soldier180E-SP), 0.68mil(Soldier180E-NP) 2D: 0.8mil(Soldier180E-SP), 1.3mil(Soldier180E-NP) |
|
| Reading Distance | |
|---|---|
| Soldier180W: 40 to 1500mm(Soldier180W-SP), 40 to 1000mm(Soldier180W-NP) Soldier180E: 40 to 2000mm(Soldier180E-SP), 40 to 1000mm(Soldier180E-NP) |
|
| Motion Tolerance | |
|---|---|
| 2m/s | |
| Min. Symbol Contrast | |
|---|---|
| ≥25% | |
| Dimensions | |
|---|---|
| 45(W) × 59.2(D) × 25(H) mm | |
| Weight | |
|---|---|
| 185g | |
| Prompt | |
|---|---|
| Buzzer,LED | |
| Current @24V DC | |
|---|---|
| Operating: 200mA (max) Standy: 70mA |
|
| Input | |
|---|---|
| Minimum ON voltage：±5V；Maximum rated voltage：±30V；2 inputs | |
| Output | |
|---|---|
| Maximum rated current：50mA per channel；Maximum voltage（OFF state）：±30V；2 outputs | |
| Communication Interface | |
|---|---|
| RS-232,TCP/IP, UDP, FTP, Modbus TCP,Ethernet/IP,Profinet,MELSEC/SLMP | |
| Operating Temperature | |
|---|---|
| -20°C to 50°C(-4°F to 122°F) | |
| Storage Temperature | |
|---|---|
| -40°C to 70°C(-40°F to 158°F) | |
| Humidity | |
|---|---|
| 5% to 95% (non-condensing) | |
| ESD | |
|---|---|
| ±16 KV (air discharge); ±8 KV (direct discharge) | |
| Sealing | |
|---|---|
| IP65 | |
| Cable | |
|---|---|
| Ethernet cable, RS232+I/O cable Reflector(optional), Magnifier(optional) |
|
| Adapter | |
|---|---|
| Input 100-240V, output DC 24V/1.5A | |
| Other | |
|---|---|
| Fixed bracket, Diffuser(optional), Reflector(optional), Magnifier(optional) | |
